JET GH-1660ZX Lathe With 300S DRO Taper Attachment And Collet Closer

Original price was: $490.00.Current price is: $84.99.

SKU: Metal Lathes jetn321391 Categories: Metal Lathes, Metalworking Tools, Power Tools

Where quality meets convenience.
We take quality seriously.
Prompt service, every time.
No-Questions-Asked Returns

Details

Features:

ISO 9001 certified manufacturer
3-1/8 in. bore spindle is supported by two tapered and one ball bearing
Chrome molybdenum headstock gears are hardened, ground and shaved
Universal gearbox allows inch, metric, diametral and module pitch threads, no gear change required
Carriage features one-shot lubrication and Turcite-B on bed sliding surfaces
T-slotted compound slide featuring a four-way tool post
One piece cast iron base absorbs vibration allowing heavier cuts
High quality ANSI Class 50 wear resistant cast iron bed ways are hardened and ground
Removable gap allows up to 23-5/8 in. diameter work on 14 in, 25-7/8 in. on 16 in, 27-1/2 in. on 18 in. and 29-1/2 in. on 22 in.
Five position automatic carriage stop increases productivity
Attractive chrome control levers, dials and knobs complete this impressive package

What’s Included:

GH-1660ZX Lathe with 300S DRO, Taper Attachment and Collet Closer – 321391
10 in. Scroll 3-Jaw Chuck with Top Reversing Jaws
12 in. Independent 4-Jaw Chuck
12 in. Face Plate (16 in. Models)
16 in. Face Plate (18 in. Models)
4-Way Tool Post
Follow Rest
Large Capacity Steady Rest
Fully Integrated Coolant System
Full Length Splash Guard and Coolant System
Large, Easy-To-Use Foot Brake
Articulating Halogen Work Lamp
Centrally Located Controls with Jog Button
Threading Dial
Mounting Pads and Levelers
Spindle Sleeve (MT-7 and MT-5)
Dead Center and Live Center

Spindle Speed Settings	12
Follow Rest Capcacity	1/2 – 3-1/2 in
Range of Longitudinal Feed Rates (IPR)	0.0015-0.0900 in
Spindle Taper (Tailstock)	MT-4
Horsepower	7.5
Voltage	230V/460V
Spindle Mount Taper	Yes
Carriage Travel	55-9/16 in
Spindle Travel (Tailstock)	5 in
Drive Type	Geared Head Clutch
No. of Longitudinal Feed Rates	46
Gap Length	12 in
No. of Cross Feed Rates	31
Swing Range (Bed)	16 in
ETL Safety	No
Spindle Mount	Yes
Length	116.5 in.
Width	40 in.
Height	48 in.
Weight	5825 lbs.
Motor Phase	3
Tool Size	1 x 1 in
Power Source	Corded
Cross Slide Travel	9 in
Range of Inch Threads (TPI)	1-5/8 – 72
Spindle Bore Diameter	3-1/8 in
PreWired Voltage	230V
UL Safety	No
Bed Width	13-3/8 in
Swing Range (Cross Slide)	10 in
No. of Inch Threads	61
Bed Construction	Cast Iron
Motor Type	Brushed
Distance Between Centers	60 in
Spindle Speed Range (RPM)	1800
Compound Slide Travel	5-1/8 in
Range of Metric Threads	0.05 – 20
Steady Rest Capacity	3/8 in – 7 in
No. of Metric Threads	24
Range of Cross Feeds (IPR)	0.0006 – 0.0360
Swing Range (Gap)	25-1/2 in
CSA Safety	No
Warranty Term	2 Year
