JET BDB-1340A Lathe With VUE Digital Readout

Original price was: $597.00.Current price is: $85.99.

SKU: Metal Lathes jetn321110 Categories: Metal Lathes, Metalworking Tools, Power Tools

Where quality meets convenience.
We take quality seriously.
Prompt service, every time.
No-Questions-Asked Returns

Details

Features:

One of the most popular JET lathes now comes with an enclosed gearbox as a standard feature
Enclosed gearbox design provides smooth, quiet operation
Fast, easy speed changes
Low voltage motor controls
Helical cut headstock gears reduce noise
Change gears allow metric threading
Spindle is supported by precision tapered roller bearings
V-way bed is induction hardened and ground
Gap bed section provided for large diameter work
Independent lead screw and feed rod
T-slotted compound slide with four-way tool post
Carriage mounted spindle control lever
Automatic feeding and threading are fully interlocked
Feed selectors travel in grooved ways
Tailstock may be offset for turning tapers and includes and inch/metric graduated quill

What’s Included:

BDB-1340A Lathe with VUE DRO – 321110
6 in. 3-Jaw Direct Mount Scroll Chuck with Top Reversing Jaw
8 in. 4-Jaw Independent Chuck
12 in. Faceplate
Steady and Follow Rest
Four-Way Tool Post
Metric Change Gear
Headstock Center Sleeve
Threading Dial
Tool Box with Tools
Oil Pan
Tolerance Test Sheet

Spindle Speed Settings	12
Follow Rest Capcacity	2-3/4 in
Range of Longitudinal Feed Rates (IPR)	0.0003-0.0103 in
Spindle Taper (Tailstock)	MT-5
Horsepower	3
Voltage	230V
Spindle Mount Taper	Yes
Carriage Travel	37-1/2 in
Spindle Travel (Tailstock)	4-3/4 in
Drive Type	Geared Head Clutch
No. of Longitudinal Feed Rates	40
Gap Length	20 in
No. of Cross Feed Rates	40
Swing Range (Bed)	14 in
ETL Safety	No
Spindle Mount	Yes
Length	71 in.
Width	32 in.
Height	25.5 in.
Weight	1070 lbs.
Motor Phase	3
Tool Size	5/8 x 5/8 in
Power Source	Corded
Cross Slide Travel	6-3/8 in
Range of Inch Threads (TPI)	4 – 112
Spindle Bore Diameter	1-1/2 in
PreWired Voltage	460V
UL Safety	No
Bed Width	10-1/2 in
Swing Range (Cross Slide)	8-1/2 in
No. of Inch Threads	40
Bed Construction	Cast Iron
Motor Type	Brushed
Distance Between Centers	40 in
Spindle Speed Range (RPM)	1800
Compound Slide Travel	3-1/2 in
Range of Metric Threads	0.45 – 7.5
Steady Rest Capacity	3-3/4 in
No. of Metric Threads	22
Range of Cross Feeds (IPR)	0.0003 – 0.0103
Swing Range (Gap)	20 in
CSA Safety	No
Warranty Term	2 Year
