Name: Assorted JET 322486 GH-1880ZX Lathe With TAK And Collet Closer styles adds a stylistic touch
SKU: Metal Lathes jetn322486
Price: 85.99 USD
Availability: InStock

Sale!

JET 322486 GH-1880ZX Lathe With TAK And Collet Closer

Original price was: $414.00.Current price is: $85.99.

SKU: Metal Lathes jetn322486 Categories: Metal Lathes, Metalworking Tools, Power Tools

Where quality meets convenience.
We take quality seriously.
Prompt service, every time.
No-Questions-Asked Returns

Details

The ZX-Series Large Spindle Bore Lathe provides power, precision, efficiency and reliability to your metal shop. A one piece cast iron base absorbs vibrations during operation to allow heavier cuts and ensure accuracy, while the Universal Gearbox eliminates the need to change gears. Features you’ve come to expect in a JET Lathe that is backed by the industry-leading JET Two Year Warranty.

Features:

3-1/8 in. bore spindle is supported by two tapered and one ball bearings
Chrome molybdenum headstock gears are hardened, ground and shaved
Universal gearbox allows inch, metric, diametral and module pitch threads, no change gears required
Carriage features one-shot lubrication and Turcite-B on bed sliding surfaces
T-slotted compound slide featuring four-way tool post
One piece cast iron base absorbs vibration allowing heavier cuts
High quality ANSI Class 50 wear resistant cast iron bed ways are hardened and ground
Removable gap allows large diameter work
Five position automatic carriage stop increases productivity
Attractive chrome levers, dials and knobs complete this impressive package
Meehanite Castings
Standard Equipment
10 in. 3-jaw scroll chuck with top reversing jaws
16 in. face plate
12 in. 4-jaw independent chuck

What’s Included:

GH-1880ZX Lathe with TAK and Collet Closer – 322486

Spindle Speed Settings	12
Follow Rest Capcacity	1/2 – 3-1/2 in
Carriage Travel	74-5/16 in
Spindle Speed Range (RPM)	1800
Compound Slide Travel	5-1/8 in
Range of Metric Threads	0.05 – 20
Spindle Travel (Tailstock)	5 in
Steady Rest Capacity	3/8 in – 7-3/4 in
No. of Metric Threads	24
Drive Type	Geared Head Clutch
No. of Longitudinal Feed Rates	46
Voltage	230V
No. of Cross Feed Rates	31
Swing Range (Bed)	18 in
ETL Safety	No
Spindle Mount	Yes
Length	136 in.
Width	44 in.
Height	66 in.
Weight	6590 lbs.
Spindle Mount Taper	Yes
Motor Type	Brushed
Power Source	Corded
Bed Width	13-1/8 in
Range of Inch Threads (TPI)	1-5/8 – 72
Spindle Bore Diameter	3-1/8 in
PreWired Voltage	460V
UL Safety	No
Range of Cross Feeds (IPR)	0.0006 – 0.0360
Swing Range (Gap)	27-1/2 in
CSA Safety	No
Distance Between Centers	80 in
Tool Size	1 x 1 in
Horsepower	7.5
Gap Length	12 in
Swing Range (Cross Slide)	11 in
No. of Inch Threads	61
Motor Phase	3
Range of Longitudinal Feed Rates (IPR)	0.0015-0.0900 in
Bed Construction	Cast Iron
Spindle Taper (Tailstock)	MT-5
Cross Slide Travel	9 in
Warranty Term	2 Year
